Gen 2 5C Collet Chuck System

Gen 2 5C Collet Chuck System

Chuck Size
By placing your order you agree to purchase from Global-e as the merchant of record, subject to Global-e’s Terms and Conditions and Privacy Policy, and share your information with Nub Tools.
$1,401.00
$1,401.00
Sale Sold out
Shipping calculated at checkout.
IF THE SIZE YOU ARE LOOKING FOR IS OUT OF STOCK, PLEASE REACH OUT TO ONE OF OUR DISTRIBUTORS:
US Shop Tools Contact
Penn Tool Co   Contact

LONG LEAD TIME- SEE DETAILS

All orders placed with us directly will not begin shipping until July 31st. Please do not order if you cannot wait. Ordering now simply gets you a place in line. All orders will be manufactured in the order they are received. Contact us if you have any questions. Thank you


The Nub Tools CNC Collet Chuck System, also known as a "Master Jaw System", is for CNC power chucks. A cost effective and efficient alternative to a standard collet chuck that eliminates the need to remove your chuck from the machine. This system provides a positive stop-dead length for repeatable part lengths when using a collet workstop. Installation is as fast and easy as installing a set of soft jaws. The ability to switch workholding with standard jaws to running collets in just minutes will skyrocket your shop's productivity.

*A total runout average of .001" - .003" can be expected out of the box with a chuck in good condition and quality collets.

Find the collet system that matches your specifications.  If you don't see matching specification for your chuck, please Contact Us to determine the correct system needed.

Fitment:

Your chuck must have a minimum chuck bore inside diameter of 45mm.

Jaw Specifications:
Chuck               Groove          Hole Spacing
  6"               .472" (12mm)       .787" (20mm)
  8"               .551" (14mm)       .984" (25mm)
10"               .630" (16mm)     1.181" (30mm)
12"               .827" (21mm)     1.181" (30mm)
*All Jaws have a 1.5mm x 60 Degree Serration
*All Jaws are 2" Tall



*T-nuts and jaw mounting bolts not included.

*Run out is measured with a 2" long pin, 1" hang out. Proper material support with long bars is crucial. Your collet jaws can be skim cut to be true to your machine for greater accuracy. Instructions provided.
